You can have an Electric Radiator that looks like this

We have two new valves to add to our range. Both are made by Carron. They are - as with all of our valves  - suitable for use with any of our Cast Iron Radiators.




Carron Satin Nickel Daisy Wheel Valve

There are two types of radiator valve available to buy: - Thermostatic and Manual.
Both Thermostatic and manual valves are sold in pairs - you will receive a valve and a lockshield.
The Control Valve is the larger of the two items and the lockshield is the smaller item.
By convention looking from within the room at your radiator:
The control valve (which is adjustable by the home owner) is fitted on the right hand side (inlet)
The lock shield (which is set up by the plumber who installs the radiator and is then left in this position) is fitted on the left hand side (outlet)


Thermostatic Radiator Valves

These valves give the optimum of control; they are designed to turn off the radiator once the room temperature has been met.
The wheel handle can be turned which adjusts the room temperature setting.




Manual Radiator Valves

These valves give the more traditional look to your radiators.
These valves allow you to adjust the radiator temperature by easily turning the valve.






The following notes are to be read before fitting your valves
When screwing the valve tail into the bush - turn it finger tight then using a spanner turn it till there is only moderate resistance.

Using a 4” (100mm) spanner it is difficult to over tighten.

It is easy to over tighten and crack the bush with an 8” spanner.

A thread sealant must be applied to the valve tail threads to get a water tight seal.

Sealants are available from your plumbers, PTFE tape is an acceptable alternative.
It should not normally be necessary to unscrew the bushes, but if for any reason you do, retighten them gently, enough only to create a good seal.
18” Stilsons should not be used!
The torque from an 8” adjustable spanner is more than enough to create a good seal.

We have a range of 6 different colours/finishes of sleeve kits.

The sleeve kit is designed to fit over the inlet and outlet pipes, the inlet and outlet pipes are normally 15mm copper, 10mm copper of nowdays 15mm plastic, the sleeve kit slides over these pipes to make a clean and tidy job.

Most modern systems run at Delta 60

ie the temperature into the radiator is 80 and the desired room temperature is 20


80 minus 20 = 60  that is why we quote at Delta 60



A recent customer had a situation where is temperature into the radiator was 75 and he wanted his room to be 20

so he needed Delta 55 figures

as shown below - he needed to up his radiators by a factor of 1.11

ie if the requirement would of been for 10 sections of radiator in a normal situation then he needed to go upto 11 sections of radiator - this would ensure he ended up with the room temperature of 20

If you need any more help on this matter then please call Viv, Dan or Becky




•Delta T = 55°: x 1.11


•Delta T = 50°: x 1.28

•Delta T = 45°: x 1.43

•Delta T = 40°: x 1.67

•Delta T = 35°: x 1.95

•Delta T = 30°: x 2.36

•Delta T = 25°: x 2.96

•Delta T = 20°: x 3.91

•Delta T = 15°: x 5.6
